LONG READ RANGES ABS UHF RFID TAGS Anti-Collision MOUNT TO ANY SURFACE MATERIAL
The A.N.G Tag Ultra Curve version is arched to hug metallic kegs or gas cylinders, and durably withstands typical washing and disinfection versions of the tags enable UHF performance for space-restricted applications, and are configured for attachment via screw or weld.
RFID Three-dimensional warehouse and logistics management
This system is suitable for manufacturing warehouse in the industrial enterprises, logistics and transit warehouses, retail stores, warehouse and telecommunications, electricity and other enterprises and institutions, asset management warehouse.
Warehouse management systems typically use a bar code label or manual warehouse management documents, these management methods have obvious shortcomings:
◎ bar code management: easy to copy, not anti-fouling, moisture and can only be read closely;
◎ Input manually: tedious work, large volumes of data prone to errors and omissions, increase the labor costs of storage areas;
◎ manual inventory produce the heavy workload;long inventory cycle,and the missing or theft of goods can not be found in a timely manner;
The introduction of the RFID technology, it will make the enterprise warehouse management becomes transparent and efficient work. The electronic tag is encapsulated within the bar code label affixed to the packaging of each cargo or tray, Tag is written with the goods, storage location and other information. And meantime Writing served on the side details of the goods out of warehouses, warehouse and distribution channels
Set fixed or handheld readers to identify, monitor the flow of goods.
Feature:
- Based on independent intellectual property development, adapt tag to work with global frequency range
- Linearly polarized design with ultra-high read rates in a particular direction, high sensitivity tag identification
- High security performance, has a globally unique identifier (TID code)
- Widely used in retail, logistics, production management, asset management
| Protocol | EPC CLASS1 Gen 2/ISO 18000-6C |
| Chip | Impinj Monza 4QT Chip |
| Work Frequency | 860—960MHZ |
| Storage Capacity | 96bit |
| Dimension | 135 * 15 * 8 mm |
| Work Mode | Read/Write |
| Storage Time | ＞10 years |
| Erasable Times | ＞100,000 times |
| Material | ABS Plastic |
| Installation | Screws, rivets installation |
APPLICATION AREAS:
■Asset tracking and logistics
- Postal and road toll management:
-truck, wagon and train tracking
- Supply chain management:
-pallet and goods tracking
■Waste management
- Commercial and industrial
-bin identification
■Returnable transport items
- Shipping container tracking
- Metal keg and gas cylinder
•Basic parameters
| •Environmental parameters |
| Operating Temp | -30℃~+50℃ |
| Storage Temp | -40℃~+100℃ |
| •Specific applications |
| Applications | Asset tracking and logistics/Waste management/Returnable transport items |
| •Packaging and delivery |
| Package | 200/ box(Customized Design) |
If you are interested in this tag, please welcome to send us an inquiry!
